Listed as Coming Soon around 14 September 2026 with no press release, datasheet, price or date. NVIDIA marks the whole specification table as preliminary, so this page is recorded as vendor claimed. Neither NVIDIA nor PNY has published an FP32 TFLOPS or AI TOPS figure, so the precision table shows support without values. A liquid-cooled version is offered in the RXM form factor; only the air-cooled card is recorded here. PNY's 416-bit memory interface does not fit 84 GB with 3 GB GDDR7 devices and may be a typo for 448-bit.

NVIDIA RTX PRO 5500 Blackwell Workstation Edition NEW

Architecture: BlackwellForm factor: PCIeAnnounced: 2026Process: 4nmStatus: Announced, not shippingSpec confidence: Vendor claimed
Memory
84 GB
GDDR7
Bandwidth
1.4 TB/s
memory
TDP
600 W
NVIDIA RTX PRO 5500 Blackwell Workstation Edition: a black dual-slot card with a fan module at the rear.
Image: NVIDIA

Overview

The NVIDIA RTX PRO 5500 Blackwell Workstation Edition is a professional Blackwell desktop card with 84 GB of GDDR7 and ECC, 1,398 GB/s of memory bandwidth and a 600 W board power, announced in September 2026 and not yet shipping. It slots into the gap between the RTX PRO 5000 Blackwell, which tops out at 72 GB and 300 W, and the RTX PRO 6000 Blackwell Workstation Edition at 96 GB and 600 W, a gap that had been wide enough to leave buyers choosing between half the memory or the full price. Its 21,760 CUDA cores are exactly the count in the GeForce RTX 5090, on the same full-size GB202 die, but with 84 GB of ECC memory in place of the 5090's 32 GB, professional driver certification and Multi-Instance GPU. That last part matters for the way NVIDIA is positioning the card: it is built for rack-mounted deployment rather than a desk, so an IT team can put the cards in a managed rack, split each one into two isolated 42 GB instances and hand workstation-class graphics and AI to people who never see the hardware. What NVIDIA has not published is any throughput figure. There is no single-precision number and no AI TOPS number on either NVIDIA's page or PNY's, so Flopper shows the datatypes the card supports and leaves the rates blank until a datasheet exists.

Performance

Peak theoretical throughput by precision type

PrecisionDense2:4 Sparse
FP64
64-bit floating point
No verified data available Structured sparsity is a tensor-core feature; this vector precision has no sparse form
FP32
32-bit floating point
No verified data available Structured sparsity is a tensor-core feature; this vector precision has no sparse form
TF32
TensorFloat-32
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
BF16
Brain Float 16
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
FP16
16-bit floating point
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
FP8
8-bit floating point
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
FP6
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
FP4
4-bit floating point
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision
INT8
8-bit integer
No verified data available The part supports 2:4 sparsity, but the vendor publishes no sparse figure for this precision

Flopper holds no verified throughput figures for this part yet. The rows stay so the gaps are visible.

Specifications

Architecture

Blackwell

Form Factor

PCIe

Launch Year

2026

Process Node

4nm

Memory

84 GB GDDR7

Bandwidth

1,398 GB/s

TDP

600 W

Max power

600 W

Transistors

92.2 billion

CUDA Cores

21,760

Spec Confidence

Vendor claimed

Full Specifications

Compute Engine
CUDA Cores 21,760
Streaming Multiprocessors 170
Chip Design
Transistors 92.2 billion
Die Size 750 mm²
Process Node 4nm
Memory
Memory 84 GB
Memory Type GDDR7
Bandwidth 1.4 TB/s
Interface Width 416-bit
Interconnect & I/O
PCIe 5.0 x16
Power & Thermal
TDP 600 W
Max power 600 W
Power Connector 1x PCIe CEM5 16-pin
Cooling Active
Enterprise Features
ECC Memory Yes
MIG Support Up to 2x 42GB, Up to 1x 84GB
Sparsity Yes
Physical & Media
Card Length 281.9 mm
Width 2-slot
NVENC Engines 3
NVDEC Engines 3
General
Form Factor PCIe
Architecture Blackwell
Process Node 4nm
Launch Year 2026

Datasheet & Resources

Flopper Datasheet

NVIDIA RTX PRO 5500 Blackwell Workstation Edition specifications, generated from our database. Printable.

NVIDIA RTX PRO 5500 Blackwell Workstation Edition product page

NVIDIA · Latest version

View

NVIDIA Developer Documentation

Technical specs, programming guides

Browse

Data Provenance

Every figure traced to a source

Primary Source

Publisher
NVIDIA
Published
No verified data available

Data Quality

Spec confidence
Vendor claimed
Clock basis
Boost
Core precisions with figures
0 of 9
Normalization
All values in TFLOPS

Compare cloud providers offering on-demand GPU instances for AI training, inference, and HPC workloads.

Browse GPU Cloud Providers

Similar GPUs

Frequently Asked Questions

How many TFLOPS does the NVIDIA RTX PRO 5500 Blackwell have?

Flopper does not currently have any verified throughput figures for the NVIDIA RTX PRO 5500 Blackwell.

What is the power consumption of the NVIDIA RTX PRO 5500 Blackwell?

The NVIDIA RTX PRO 5500 Blackwell has a TDP (Thermal Design Power) rating of 600 watts.

How much memory does the NVIDIA RTX PRO 5500 Blackwell have?

The NVIDIA RTX PRO 5500 Blackwell is equipped with 84 GB of memory with 1,398 GB/s of memory bandwidth.

What architecture is the NVIDIA RTX PRO 5500 Blackwell based on?

The NVIDIA RTX PRO 5500 Blackwell is based on the Blackwell architecture, launched in 2026.
